Most
Android apps have some sort of server-side back end, to persist and
share data. Even the most basic game needs to remember its players’ high
scores. When you’re building your back end, one problem you have to
solve is how the back-end code knows what app it’s talking to and who
the person using it is.
You probably have HTTP endpoints for
communicating with your client apps, but how can the server-side code be
sure who’s sending messages to it? After all, anyone can send HTTP POST
requests from anywhere; could they impersonate your users if they could
guess their identities?
It’s really user-unfriendly to ask people
to type in usernames and passwords on mobile devices. In particular, if
someone has installed your app and given it permission to use the
Internet and know your identity, they shouldn’t be pestered any more.
It turns out that
Google Play services,
now available on every compatible device running Android release 2.2 or
higher, offers a good solution to this problem, based on the use of
Google Accounts.
Summary
Doing this is a multi-step process, which I’ll outline in full, but here’s the short version: You use the
GoogleAuthUtil
class, available through Google Play services, to retrieve a string
called an “ID Token”. You send the token to your back end and your back
end can use it to quickly and cheaply verify which app sent it and who
was using the app.
This capability is built into Google facilities such as App Engine’s new
Cloud Endpoints feature, which bakes app/back-end identity into a simple programming model.
Now let’s get to the details.
App Registration
You’re going to have to use the
Google API Console
quite a bit in this process. You’ll need to make a new project for this
purpose; while you can give it a nice human-readable name and graphical
branding, it turns out that those resources aren’t used in this
particular scenario.
You can also authorize this project to
access a large number of different Google APIs; but once again, you
don’t need to in this scenario.
You should give serious thought to
the people you authorize as members of the project, since these are
important administrative roles.
Make Client IDs
You’ll
need to make two different OAuth 2.0 “Client IDs” for your project. The
first one is a “Client ID for Web applications”. Once again, you can
ignore all the labeling and branding stuff, you’ll just need the
Client-ID string, which will look something like
9414861317621.apps.googleusercontent.com.
Now
you’ll need to make another Client ID for your Android app. To do this,
you’ll need to provide two pieces of information: your app’s package
name and cert signature. The package name is just the Java-style
reverse-DNS, as given in the top-level “package” attribute in your
AndroidManifest.xml, for example
com.example.identity.
To get your app’s cert signature, use the following shell command:
$ keytool -exportcert -alias <your-key-name> -keystore <your-key-store-file> -v -list
Copy
the octets labeled “SHA1”, paste them into the Developer Console field,
and create your app’s Client ID. Once again, all you’ll really need
from the readout is the Client-ID string.
In Your Android App
You’ll need to call the Google Play services
GoogleAuthUtil class to get an ID token; the procedure is as described in
Obtaining an Access Token. There’s one extra bit of magic: the value of the
scope argument to the
getToken(email, scope) method. It has to be the string
audience:server:client_id:X,
where X is the Client ID of for the Web app, as described above. If our
Client ID were the example value given above, the value of the scope
argument would be
audience:server:client_id:9414861317621.apps.googleusercontent.com.
Magic Happens
Normally,
when you ask for an OAuth token, the person using the device sees a
challenge, asking them if it’s OK to use their identity to get at some
resource or other. But in this case, the system looks at the server-side
Client ID in your scope argument, notices that it’s in the same project
as your Android app, and gives you the token without pestering the
user; they’ve already agreed to a relationship with you, the developer
who controls that project.
Send the Token
When you’re
ready to start talking to your server back end, you need to send the
token string to it. The best way to do this is in the body of an POST
message; you could put it in a URL parameter, but they’re often logged.
You absolutely
must use an HTTPS connection, to keep any men-in-the-middle from peeking at your token.
There’s
no particular reason for extra round-trips; if you’re sending a game
high score to your back end, just stick the ID Token string in as an
extra argument.
Use the Token
When your server receives the token from your Android app, it’s really important that you verify it. This requires two steps:
- Verify that it’s really signed by Google.
- Verify that it’s really meant for you.
Verify Signature
It turns out that this is signed using a
Google public/private key pair, and Google publishes the public keys
(which we change regularly) at
www.googleapis.com/oauth2/v1/certs; go ahead and have a look.
You have to verify that the ID Token, which is actually a
JSON Web Token,
was signed with one of those certs. Fortunately, there are decent
libraries around to do this; in this post, I’ll give pointers for Java,
Ruby, and PHP.
The libraries can cache the Google certs and only
refresh them when required, so the verification is (almost always) a
fast static call.
Verify Token Fields
It turns out that
the ID Token has a JSON payload, and most libraries that validate the
signatures also give it to you as a hash or dictionary or whatever.
Thus, you can retrieve named fields, such as
aud and
azp and
email.
First, you have to look at the field named
aud and verify that it’s identical to your Client ID, the string you included in the Android app’s scope argument. Seriously,
do not omit this step; if you don't verify the ID Token, then any other developer can spoof requests to your service.
Optionally, you can look at the field named
azp
(stands for “authorized party”) and verify that it is identical to the
Client ID of your Android app. By the way, you can have multiple
different Android client apps, each with its own Client ID, in that
top-level project.
Let’s assume you’ve done all three of these things. Then, you know that:
- The token was issued by Google.
- The token was sent to a device that was being operated by the person identified in the payload's
email field.
You also have high confidence that:
- The token was obtained by the Android app identified by the Client ID in the payload’s
azp field.
The Client ID only has “high confidence” because non-compatible
or rooted Android devices may be able to tamper with that information.
But they won't be able to fake the Google signature or the
authentication of the device user to Google.
What’s Next?
That’s up to you. You know which person and app you’re talking to, it’s up to you what to do with that information.
Code Fragments
Here’s a Java class that implements an ID-Token checker using the Google Java libraries:
import java.io.IOException;
import java.security.GeneralSecurityException;
import com.google.api.client.googleapis.auth.oauth2.GoogleIdToken;
import com.google.api.client.googleapis.auth.oauth2.GoogleIdTokenVerifier;
import com.google.api.client.http.javanet.NetHttpTransport;
import com.google.api.client.json.JsonFactory;
import com.google.api.client.json.gson.GsonFactory;
public class Checker {
private final List mClientIDs;
private final String mAudience;
private final GoogleIdTokenVerifier mVerifier;
private final JsonFactory mJFactory;
private String mProblem = "Verification failed. (Time-out?)";
public Checker(String[] clientIDs, String audience) {
mClientIDs = Arrays.asList(clientIDs);
mAudience = audience;
NetHttpTransport transport = new NetHttpTransport();
mJFactory = new GsonFactory();
mVerifier = new GoogleIdTokenVerifier(transport, mJFactory);
}
public GoogleIdToken.Payload check(String tokenString) {
GoogleIdToken.Payload payload = null;
try {
GoogleIdToken token = GoogleIdToken.parse(mJFactory, tokenString);
if (mVerifier.verify(token)) {
GoogleIdToken.Payload tempPayload = token.getPayload();
if (!tempPayload.getAudience().equals(mAudience))
mProblem = "Audience mismatch";
else if (!mClientIDs.contains(tempPayload.getIssuee()))
mProblem = "Client ID mismatch";
else
payload = tempPayload;
}
} catch (GeneralSecurityException e) {
mProblem = "Security issue: " + e.getLocalizedMessage();
} catch (IOException e) {
mProblem = "Network problem: " + e.getLocalizedMessage();
}
return payload;
}
public String problem() {
return mProblem;
}
}
If you wanted to do this in Ruby, you’d want to install the google-id-token Ruby gem, and do something like this:
require 'google-id-token'
validator = GoogleIDToken::Validator.new
jwt = validator.check(token, required_audience, required_client_id)
if jwt
email = jwt['email']
else
report "Cannot validate: #{validator.problem}"
end
